Victron SmartSolar MPPT 100/30 Bluetooth Charge Controller
Victron SmartSolar MPPT 100/30 Bluetooth Charge Controller
A genuine step up in capacity from the compact SmartSolar models, the 100/30 is built for larger 12V or 24V arrays - multiple panels on a caravan roof, or a serious off-grid shed installation - without a cooling fan to fail and without sacrificing tracking speed.
Real capacity, no derating surprises
Rated at 440W on 12V or 880W on 24V at a full 30A, the 100/30 runs fan-free with maximum efficiency exceeding 98% and full rated output guaranteed up to 40°C ambient - a meaningful spec in North Queensland heat where many controllers quietly throttle back. The same ultra-fast MPPT tracking and advanced partial-shade detection used across the SmartSolar range locks onto the true maximum power point rather than settling for a local one.
Fully discharged battery recovery
If a lithium battery's internal disconnect has triggered from over-discharge, the 100/30 will initiate charging and reconnect rather than leaving you stuck - a feature that matters more than it sounds the day you actually need it.
- Battery voltage: 12/24V, auto-select
- Rated charge current: 30A
- Nominal PV power: 440W (12V) / 880W (24V)
- Maximum PV open-circuit voltage: 100V
- Max. PV short-circuit current: 35A
- Maximum efficiency: 98%
- Charge algorithm: Multi-stage adaptive, 8 pre-programmed profiles plus custom
- Communication: Bluetooth Smart built-in, plus VE.Direct port
- Enclosure: IP43 (electronics), IP22 (connection area)
- Dimensions: 130 x 186 x 70mm
- Weight: 1.3kg
- Operating temperature: -30°C to +60°C (full output up to 40°C)
Best suited to
Larger 12V panel arrays or a serious 24V solar setup - multi-panel caravan and motorhome roofs, off-grid sheds, and any system where you're charging a substantial lithium or AGM bank from solar alone.
Pair with: two Victron BlueSolar 215W panels in parallel on 12V, or in series on 24V, for a well-matched high-output system.
