Victron BlueSolar 12V 185W Monocrystalline Solar Panel
Victron BlueSolar 12V 185W Monocrystalline Solar Panel
One of the most popular sizes in the BlueSolar range for 12V caravans, camper trailers and 4WD canopy installs - big enough to genuinely keep up with a fridge and lighting circuit, small enough to fit most standard roof spaces without major surgery.
Why this size works so well for 12V systems
At 185W STC with 9.41A maximum power current, this 36-cell monocrystalline panel is sized to charge a 12V battery bank efficiently through a PWM or MPPT controller without the excess open-circuit voltage that wastes potential on smaller systems. Victron's -0.45%/°C temperature coefficient on power output means it holds up better in Townsville heat than many panels that quote impressive STC numbers but fade once the roof gets hot.
Built like every other Victron panel - properly
Tempered high-transmission glass, triple-layer EVA back sheet encapsulation, and an anodised aluminium frame rated to 200kg/m² surface load and 23m/s hail impact, all backed by a sealed IP65 junction box (PV-LH0808) with bypass diodes for shade tolerance.
Specifications
- Nominal power: 185W (±3% tolerance)
- Max-power voltage (Vmpp): 19.68V
- Max-power current (Impp): 9.41A
- Open-circuit voltage (Voc): 24.11V
- Short-circuit current (Isc): 9.91A
- Cell type: Monocrystalline, 36 cells
- Dimensions: 1485 x 668 x 30mm
- Weight: 11kg
- Maximum system voltage: 1000V
- Junction box: PV-LH0808, IP65
- Warranty: 5 years materials and workmanship; 10 years at 90% power output, 25 years at 80% power output
Best suited to
12V caravan and camper trailer roofs, 4WD canopy fit-outs, and dual battery touring setups where you want strong daily charge without going to a 24V system.
Pair with: a Victron SmartSolar MPPT 75/15 or 100/15 for the best charge efficiency from this panel size.
